THIẾT BỊ VẬN HÀNH VAN XÁCH TAY13 sản phẩm

modec pneumatic portable valve actuators are the most compact, light and powerful. They offer a wide choice in terms of power and can be used in all environments, even the very difficult ones. You can have them ATEX II 2 GD c IIC T6 to T4 certified, they can go to stall and they don’t generate heat, sparks or smoke.

The RA30 right angle drive head can be positioned at 90° to the actuator providing optimal positioning for the operator. It is suitable for high torques (up to 630 Nm (465 lb.ft)).

The spoke adaptors clamp solidly and quickly to the handwheel and can turn in both directions, with or without a rising stem.


Included as standard. Compatible with all our adaptors range.

Although it is super light and compact, the MC89 Portable Valves Actuator delivers a 900 Nm (660 lb.ft) maximum torque. This makes it the perfect tool for any «« Easy » or « Standard » duty job, for any valve type, indoor or outdoor, with a great autonomy. Its two 18V Lithium-Ion batteries allow to use it continuously during up to one hour. For an even more intensive usage, use the main power connection kit that plugs on the actuator just like a battery and provides an unlimited autonomy.

Thanks to their long life batteries, modec electric portable valve actuators are able to deliver a high power for more than one hour. This means they are not dependent on an energy source (electric plug or compressed air network) and can operate freely anywhere. Their exceptional power for a portable tool allows to benefit from high speed and high torque at the same time. Extremely robust, they have an integrated clutch system which protects the operator and the equipment, even if a valve is completely blocked.

Essential for all rising stem handwheels, the Standard duty banjo drive head caters for all stems up to a maximum diameter of 63mm (2.48’’). It can also operate all clamping systems for handwheel and other interfaces.

The digital revolution counter adds up the turns in one direction and subtracts them in the other direction so that the operator always knows where he is in relation to the starting point. It also measures and indicates the rotating speed.

This exclusive patented system is the simplest and most effective for clamping on to flat or slightly tapered handwheels. No need to pre-install drive plates on the handwheel before use. The fingers type adaptors fix simply on to the  portable actuator head, and can then be used to turn every handwheel that has the same number of spokes. It takes less than a minute to change the adaptor. It can also be used for rising stem valves (if used with a banjo head).

These adaptors must be fixed to the handwheel before use. Thanks to their multiple “U” clamps that catch the handwheel’s spokes, they can fix on to almost every type of handwheel.

modec petrol portable valve actuators can be used in total autonomy – the only limit being the available petrol supply. They are particularly suitable for use in isolated outdoor places.


Thanks to the various interfaces, the adaptors can be used with any portable valve actuator and any head (straight, right angle or banjo).
